Krka Valley Viaduct, a concrete road deck on tall piers crossing a reservoir between mountains

Project 05Road viaduct over a reservoir

Krka Valley Viaduct

Client
Hrvatske ceste, regional roads authority
Location
Dalmatia, Croatia
Year
2022
Area
14,600 m²
Duration
34 months
Structural engineer
Kovač Statika, Ljubljana
01 — The projectDalmatia, Croatia, 2022

Seven piers, one line, and a reservoir that never had to be drained.

The Krka Valley Viaduct carries a new regional road 640 metres across a reservoir in the Dalmatian hinterland, replacing a winding mountain route that closed every winter.

Its seven piers were cast inside cofferdams sunk into the reservoir bed, so the water level and the fish never had to change. The deck was launched incrementally from the eastern abutment, eighteen metres at a time.

Every pier was surveyed twice a day while the deck slid across it. The road opened to traffic in the autumn of 2022, four weeks ahead of programme.

Site 43°48′17″N 015°58′41″E

Board-marked concrete pier carrying the underside of the deck against a pale sky
Fig. 02 — A pier head and the deck above it, cast in place
Fig. 03 — Ground floor plan1:200
Close-up of pale board-formed concrete
Fig. 04 — Pier concrete, cast in climbing formwork
Detail of Krka Valley Viaduct
Fig. 05 — Detail of the finished building
02 — Materials and specifications06 items
Length
640 m, nine spans
Piers
Seven, up to 48 m tall, cast in cofferdams
Deck
Post-tensioned box girder, launched incrementally
Foundations
Bored piles, 1.5 m diameter, into limestone
Design life
120 years
Programme
Opened four weeks ahead of schedule
